Mutant Metals Ultimate Dip Attachment (UDA)

★★★★★
★★★★★
0
0 Reviews
Made in U.S.A.

Mutant Metals Ultimate Dip Attachment (UDA)

★★★★★
★★★★★
0
0 Reviews
Made in U.S.A.
CA$445.00
Ships in 4-6 weeks.
1" Pin is Compatible with Rogue Monster Uprights
5/8” Pin is Compatible with Rogue Monster Lite Uprights
Product Description

The Ultimate Dip Attachment (UDA) from Mutant Metals is now available in several exclusive Rogue-built variations. This modular rack attachment is compatible with both Monster and Monster Lite units, and features removable, knurled handles, enabling athletes to adjust the handle spacing to best suit their size and training goals.

Read More

Mutant Metals Ultimate Dip Attachment (UDA)

The Ultimate Dip Attachment (UDA) from Mutant Metals is now available in several exclusive Rogue-built variations. This modular rack attachment is compatible with both Monster and Monster Lite units, and features removable, knurled handles, enabling athletes to adjust the handle spacing to best suit their size and training goals.

The UDA’s 3 Handle Ranges:

  • Position 1: 11.5 - 20”
  • Position 2: 15 - 24”
  • Position 3: 19 - 27.5”

4 Current Variations of the Rogue-Built Ultimate Dip Attachment:

  • 1” Pin* - Standard (Texture Black Frame w/ Texture Black Pin, Matte Black Knurled Handles )
  • 1” Pin* - Stainless Steel (Texture Black Frame w/ Stainless pin, Stainless Knurled Handles)
  • 5/8” Pin** - Standard (Texture Black Frame, ⅝” Detent pin, Matte Black Knurled Handles)
  • 5/8” Pin** - Stainless Steel (Texture Black Frame, ⅝” Detent pin, Stainless Knurled Handles)


*Compatible with Rogue Monster Uprights
**Compatible with Rogue Monster Lite Uprights

Note: Additional frame colorways will be available in the future.

The attachment mounts easily to an upright using either an integrated 1” pin (for Rogue Monster Uprights) or removable ⅝” detent pin (for Rogue Monster Lite Uprights). Handle adjustments can be made quickly from one athlete to the next using the Rogue patented knurled knob. The 1-3/8” diameter handles provide 18” of usable length, and they’re available in two finish options: Stainless Steel or our Proprietary Matte Black. Convenient knurl marks appear every 6” along each handle to help the user find and repeat a comfortable starting position from workout to workout. We have also included protective UHMW on all contacting surfaces to help protect both the attachment and the rack upright (this protection still applies when the UDA is in “storage mode”).

Gear Specs

Specifications:

  • Made in the USA
  • Available as a 1” welded pin or  5/8” hole and detent pin
  • 2x2” 11-gauge and 3/8” thick welded steel frame - Texture Black finish
  • 12.6 LB Frame, ~8.6 LB per handle
  • 3 Handle Width Options
  • Handle Diameter of 1 3/8”
  • Handle Finish Options: Proprietary Matte Black Knurled or Stainless Steel Knurled (with knurl marks every 6”)
  • Usable Handle Length: 18”
  • Built in storage (with plastic protection)
  • Texture Black frame finish (additional colors to be available in the future)
  • Max Handle Width: approx 27.5”
  • Min Handle Width: approx 11.5”
  • Dims: 21.25 W x 6.75 H x 24.5 D (from mounting upright)
  • Weight limit: 550lbs
Shipping

Rogue Fast Shipping

The Rogue Shipping System allows you to track your order from the time you place it to the time it hits your door. Order today, track today.

Loading

Gear Specs

BrandMutant Metals
Made In USAYes
Product Weight31LB
LengthApproximately 24.5" (depth from mounting upright - varies based on handle position)
Width21.25" (Frame)
Height6.75"
Diameter1-3/8" / 35mm (Handle)
Steel Notes2 x 2" 11-Gauge Steel / ⅜” Steel Plates
Other Product Specs18" Usable Handle Length

Key Features of the UDA

Loading
1

Designed in Partnership with Mutant Metals

The Ultimate Dip Attachment was first developed by Mutant Metals, a family owned and operated manufacturer of quality strength training equipment, based in western Pennsylvania. Rogue was pleased to work with Mutant Metals on adapting our own versions of this accessory, which are manufactured here in Columbus with their blessing.

Loading
2

Removable Handles - 3 Width Options

The UDA creates an instant dip station on an existing 3x3” Monster or Monster Lite rack/rig, attaching securely via an included pin (1” for the Monster version, 5/8” for the Monster Lite). The attachment’s 1-3/8” diameter handles can also be removed and placed in one of three holes, then secured quickly using the Rogue patented knurled knob . This creates three handle width options with their own grip spacing ranges: Narrow (11.5” - 20”), Mid (15” - 24”), and Wide (19” - 27.5”). The handles will remain at the same 30-degree angle in relation to one another no matter where they are positioned.

Loading
3

Handle Knurling + 2 Finish Options

All UDA handles have 18” of usable length and are knurled for a superior grip, with convenient knurl marks provided every 6” to help athletes repeat comfortable starting grip positions. Customers can select between a Stainless Steel handle finish or our Proprietary Matte Black finish, which utilizes a process that effectively transforms the surface of the steel rather than coating it, greatly increasing the handles’ long-term corrosion resistance and color endurance. Additional frame colorways will be available in the future.

Loading
4

Quality Rogue Construction

Rogue has made some notable adaptations to the original Mutant Metals UDA design, including the use of a single-piece formed and welded tube; reinforcement of the frame with a tubular triangle gusset; and the introduction of a Rogue patented knurled knob for set-up with an integrated protective plastic washer. All welded joints are also slotted/tabbed prior to welding for additional structural strength. Tight tolerances are enforced to ensure a more snug fit on the upright. Every Ultimate Dip Attachment we manufacture is fully built out and tested, with modifications made to any that don’t meet the tightness requirements.
